800 WOG Y-Check Valve, Threaded
- Investment cast body & cap
- Screwed-in cap
- Connecting threads: ANSI B2.1/BS21
Additional Information
| NO. | 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 |
| PART NAME | BODY | CAP | SPRING | DISC | SEAT | WASHER | BOLT | GASKET PACKING |
| MATERIAL | ASTM A351 Gr. CF8M | ASTM A351 Gr. CF8M | SS304 | SS316 | TEFLON | SS304 | SS304 | TEFLON |
| Quantity | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
